The next article applies for the models listed below:
Interactive UPS: SL Series, FX Series, CL Series.
The following article provides the backtime for each UPS from model SL-500 to the FX series.
| Model | Capacity | 25% Load | 50% Load | 75% Load | 100% Load |
|---|---|---|---|---|---|
| CL-750B | 750VA/375W | 18 min. (93 watts) | 5 min. (187 watts) | 1 min. (281 watts) | 0.5 min. (375 watts) |
| FX-1500LCD | 1500VA/ 900W | 20min. (225 watts) | 6.5 min. (450 watts) | 4 min. (675 watts) | 1.5min. (900 watts) |
| FX-1500LCD-C | 1500VA/ 900W | 20 min. (225 watts) | 6.5 min. (450 watts) | 3 min. (675 watts) | 1.4min. (900 watts) |
| FX-1500LCD-U | 1500VA/ 900W | 20 min. (225 watts) | 6.5 min. (450 watts) | 3 min. (675 watts) | 1.4min. (900 watts) |
| FX-2200LCD | 2200VA/1200W | 16 min. (300 watts) | 5 min. (600 watts) | 2.5min. (900 watts) | 0.5min. (1200 watts) |
| FX-2200LCD-C | 2200VA/1200W | 16 min. (300 watts) | 3.5 min. (600 watts) | 1.5 min. (900 watts) | 1 min. (1200 watts) |
| FX-2200LCD-U | 2200VA/1200W | 16 min. (300 watts) | 3.5 min. (600 watts) | 1.5 min. (900 watts) | 1 min. (1200 watts) |
| FX-650LCD | 650VA/360W | 19 min. (90 watts) | 7 min. (180 watts) | 1 min. (270 watts) | 0.5 min. (360 watts) |
| FX-650LCD-U | 650VA/360W | 19 min. (90 watts) | 7 min. (180 watts) | 1 min. (270 watts) | 0.5 min. (360 watts) |
| FX-900LCD | 900VA/495W | 19 min. (123 watts) | 2 min. (247 watts) | 1 min. (371 watts) | 0.5 min. (495 watts) |
| FX-900LCD-U | 900VA/495W | 19 min. (123 watts) | 2 min. (247 watts) | 1 min. (371 watts) | 0.5 min. (495 watts) |
| HT-1000 | 1000VA/500W | 21min (125 watts) | 8min(250 watts) | 4min(375 watts) | 2.1min(500 watts) |
| HT-750 | 750VA/375W | 24min (90 watts) | 9min (180 watts) | 4min (270 watts) | 2.3min (360 watts) |
| NT-1001 | 800VA/480W | 15 min. (120 watts) | 5.5 min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| NT-1001D | 800VA/480W | 15 min. (120 watts) | 5.5 min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| NT-1002A | 800VA/480W | 15 min. (120 watts) | 3min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| NT-1002C | 800VA/480W | 15 min. (120 watts) | 3min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| NT-1002U | 800VA/480W | 15 min. (120 watts) | 3min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| NT-1011 | 800VA/480W | 15 min. (120 watts) | 5.5 min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| NT-1011D | 800VA/480W | 15 min. (120 watts) | 5.5 min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| NT-1012U | 800VA/480W | 15 min. (120 watts) | 3min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| NT-501 | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| NT-501D | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| NT-502A | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| NT-502C | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| NT-502U | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| NT-511 | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| NT-511D | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| NT-512U | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| NT-751 | 750VA/375W | 15 min. (93 watts) | 6 min. (187 watts) | 30 sec. (281 watts) | 1sec. (375 watts) |
| NT-751D | 750VA/375W | 15 min. (93 watts) | 6 min. (180 watts) | 30 sec. (281 watts) | 1sec. (375 watts) |
| NT-752A | 750VA/375W | 15 min. (93 watts) | 5.5 min(180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| NT-752U | 750VA/375W | 15 min. (93 watts) | 6 min. (180 watts) | 30 sec. (281 watts) | 1sec. (375 watts) |
| NT-761 | 750VA/375W | 15 min. (93 watts) | 6 min. (180 watts) | 30 sec. (281 watts) | 1sec. (375 watts) |
| NT-761D | 750VA/375W | 15 min. (90 watts) | 6 min. (180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| NT-762C | 750VA/375W | 15 min. (93 watts) | 6 min. (180 watts) | 30 sec. (281 watts) | 1sec. (375 watts) |
| NT-762U | 600VA/360W | 15 min. (93 watts) | 6 min. (180 watts) | 30 sec. (281 watts) | 1sec. (375 watts) |
| SL-1001 | 1000VA/600W | 25 min. (150 watts) | 10 min. (300 watts) | 4 min. (450 watts) | 2 min. (600 watts) |
| SL-1001D | 1000VA/600W | 25 min. (150 watts) | 10 min. (300 watts) | 4 min. (450 watts) | 2 min. (600 watts) |
| SL-1002C | 1000VA/600W | 25 min. (150 watts) | 10 min. (300 watts) | 4 min. (450 watts) | 2 min. (600 watts) |
| SL-1002U | 1000VA/600W | 25 min. (150 watts) | 10 min. (300 watts) | 4 min. (450 watts) | 2 min. (600 watts) |
| SL-1011 | 1000VA/600W | 25 min. (150 watts) | 9.5min. (300 watts) | 3.4min. (450 watts) | 28sec. (600 watts) |
| SL-1011D | 1000VA/600W | 25 min. (150 watts) | 9.5min. (300 watts) | 3.4min. (450 watts) | 28sec. (600 watts) |
| SL-1011LCD | 1000VA/600W | 25 min. (150 watts) | 9.5min. (300 watts) | 3.4min. (450 watts) | 28sec. (600 watts) |
| SL-1011LCD-D | 1000VA/600W | 25 min. (150 watts) | 9.5min. (300 watts) | 3.4min. (450 watts) | 28sec. (600 watts) |
| SL-1011UL | 1000VA/600W | 20min. (150 watts) | 5.5min. (300 watts) | 2min. (450 watts) | 1sec. (600 watts) |
| SL-1012A | 1000VA/600W | 25 min. (150 watts) | 10 min. (300 watts) | 4 min. (450 watts) | 2 min. (600 watts) |
| SL-1012C | 1000VA/600W | 25 min. (150 watts) | 5 min. (300 watts) | 2 min. (450 watts) | 30sec. (600 watts) |
| SL-1012LCD-C | 1000VA/600W | 25 min. (150 watts) | 5 min. (300 watts) | 2 min. (450 watts) | 30sec. (600 watts) |
| SL-1012LCD-U | 1000VA/600W | 25 min. (150 watts) | 5 min. (300 watts) | 2 min. (450 watts) | 30sec. (600 watts) |
| SL-1012U | 1000VA/600W | 25 min. (150 watts) | 5 min. (300 watts) | 2 min. (450 watts) | 30sec. (600 watts) |
| SL-1012UL-A | 1000VA/600W | 20min. (150 watts) | 5.5min. (300 watts) | 2min. (450 watts) | 1sec. (600 watts) |
| SL-401UL | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| SL-501 | 500VA/250W | 16 min. (62 watts) | 7 min. (125 watts) | 2 min. (187 watts) | 0.5 min. (250 watts) |
| SL-501D | 500VA/250W | 16 min. (62 watts) | 7 min. (125 watts) | 2 min. (187 watts) | 0.5 min. (250 watts) |
| SL-502C | 500VA/250W | 16 min. (62 watts) | 7 min. (125 watts) | 2 min. (187 watts) | 0.5 min. (250 watts) |
| SL-502U | 500VA/250W | 16 min. (62 watts) | 7 min. (125 watts) | 2 min. (187 watts) | 0.5 min. (250 watts) |
| SL-511 | 400VA/240W | 16 min. (60 watts) | 7 min. (120 watts) | 2 min. (180 watts) | 0.5 min. (240 watts) |
| SL-511D | 500VA/250W | 16 min. (62 watts) | 7 min. (125 watts) | 2 min. (187 watts) | 0.5 min. (250 watts) |
| SL-512A | 500VA/250W | 16 min. (62 watts) | 7 min. (125 watts) | 2 min. (187 watts) | 0.5 min. (250 watts) |
| SL-512C | 500VA/250W | 16 min. (62 watts) | 7 min. (125 watts) | 2 min. (187 watts) | 0.5 min. (250 watts) |
| SL-512U | 500VA/250W | 16 min. (62 watts) | 7 min. (125 watts) | 2 min. (187 watts) | 0.5 min. (250 watts) |
| SL-601UL | 600VA/360W | 15 min. (90 watts) | 6 min. (180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| SL-751 | 750VA/375W | 18 min. (93 watts) | 5 min. (187 watts) | 1 min. (281 watts) | 0.5 min. (375 watts) |
| SL-751D | 750VA/375W | 18 min. (93 watts) | 5 min. (187 watts) | 1 min. (281 watts) | 0.5 min. (375 watts) |
| SL-752C | 750VA/375W | 18 min. (93 watts) | 5 min. (187 watts) | 1 min. (281 watts) | 0.5 min. (375 watts) |
| SL-752U | 750VA/375W | 18 min. (93 watts) | 5 min. (187 watts) | 1 min. (281 watts) | 0.5 min. (375 watts) |
| SL-761 | 600VA/360W | 15 min. (90 watts) | 6 min. (180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| SL-761D | 600VA/360W | 15 min. (90 watts) | 6 min. (180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| SL-761LCD | 600VA/360W | 15 min. (90 watts) | 6 min. (180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| SL-761LCD-D | 600VA/360W | 15 min. (90 watts) | 6 min. (180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| SL-762A | 750VA/375W | 18 min. (93 watts) | 5 min. (187 watts) | 1 min. (281 watts) | 1sec. (360 watts) |
| SL-762C | 600VA/360W | 15 min. (90 watts) | 5.5 min(180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| SL-762LCD-C | 600VA/360W | 15 min. (90 watts) | 5.5 min(180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| SL-762LCD-U | 600VA/360W | 15 min. (90 watts) | 5.5 min(180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| SL-762U | 600VA/360W | 15 min. (90 watts) | 5.5 min(180 watts) | 30 sec. (270 watts) | 1sec. (360 watts) |
| SL-800UL | 800VA/480W | 15 min. (120 watts) | 5.5 min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| SL-801UL | 800VA/480W | 15 min. (120 watts) | 5.5 min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
| SL-802UL-A | 800VA/480W | 15 min. (120 watts) | 5.5 min. (240 watts) | 20 sec (360 watts) | 1sec. (480 watts) |
